30bbl Unitank

Cassman 30bbl unitanks are all Tig welded by 304 Stainless Steel for interior/Exterior. Our Unitanks combine the uses of a regular fermenter and a brite tank into a single vessel, allowing the brewer the ability to ferment and carbonate their beer in one vessel, saving valuable floor space.

Specifications

Interior/Exterior Tig welded 304 Stainless Steel

3mm interior tank wall thickness

2mm exterior shell wall thickness

3" Thick polyurethane insulation on shell and cone

2B sanitary interior polish

4N exterior polish (sanitary)

Adjustable feet with anchor holes

Operating pressure 20psi (Tested at 30psi)

3/4" FNPT for glycol attachment

Full rotating racking arm/ DIN Fitting (Din Fitting Wrench Included)

Full shadow less side man way door (15"x17")

20psi pressure/vacuum relief valve

Thermometer Gauge With 8" Long Thermo well

Perlick style sample valve

Oversized 2" bottom outlet with 2"-1.5" reducer (included)

1/2" FNPT for RTD temp control, 8" thermowell (RTD not included)

CIP arm with 2.5" spinning spray ball and 360deg of coverage

Dedicated blow off tube

2 piece 10" carbonation stone with ball valve

0-45 PSI, Sanitary 1.5" Tri-Clamp Pressure Gauge

Stainless steel handle Butterfly valves

60deg cone bottom with 20% head space

All necessary EPDM gaskets

All Jacketed unitanks have Hop Ports, 3.5bbl to 10bbl sizes include a 4" Hop Port Opening, 15bbl to 30bbl sizes will include a 8" Hop Port, Any sizes above 30bbl will not include this option.
